Ready Mix Concrete Plant

Description:Ready Mixed Concrete batching Plants is more commonly known as RMC Plant, it can mix aggregate, water, and additives to make concrete.

Max productivity(m³/h):25-180

Discharging height(m):1.5-4.5

Working cycle time(s):60-72

Total power (kw):50-288

Total weight:16T-70T

product Description

Ready Mixed Concrete batching Plants is more commonly known as RMC Plant, it can mix aggregate, water, and additives to make concrete. The reason why it is called ready-mixed is because the concrete is not directly applied to the building after it is produced, but needs to be transported to the construction site via concrete trucks.

Ready Mix Concrete Plants are available in stationary types(HZS25-HZS240) as well as mobile types(YHZS25-YHZS120).

Ready Mix Concrete Plants is very often preferred to the usual mixing of on-site Concrete Plants. As it can help reduce the confusion of on site labour and deliver good quality precision mixes.

Today RMC Plant is playing a very important role in building Road and Civil Structures. They offer unmatched rigidity and long life to the structure. Hence it is getting popular day by day.

Parameter

Model		HZS25	HZS35	HZS50	HZS75	HZS60	HZS90	HZS120	HZS180
Global parameter	Maximum productivity (m³/h)	25	35	50	75	60	90	120	180
	Discharging height (m)	1.5–4.2	1.6–4.2	4.2	4.2	4.2	4.2-4.5	4.5	4.5
	Working cycle time(s)	72	72	72	72	60	60	60	60
	Total power (kw)	50	75	88	110	105	145	210	288
Mixer	Model	JS500	JS750	JS1000	JS1500	JS1000	JS1500	JS2000	JS3000
Batcher	Model	PLD800	PLD1200	PLD1600	PLD2400	PLD1600	PLD2400	PLD3200	PLD4800
Pneumatic system	Air compressor	1.0–7	1.0–7	1.5–7	1.8–7	1.5–7	1.8–7	1.8–7	1.8–7
	Discharge pressure(MPa)	0.8	0.8	0.8	0.8	0.8	0.8	0.8	0.8
	Displacement (m³/min)	1.67	1.67	1.67	1.67	1.67	1.67	1.67	1.67
	Motor power	5.5	5.5	7.5	11	7.5	11	11×2	11×2
Measurement system	Aggregate weighing accuracy	±2%	±2%	±2%	±2%	±2%	±2%	±2%	±2%
	Cement weighing accuracy	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
	Water weighing accuracy	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
	Additive weighing accuracy	±1%	±1%	±1%	±1%	±1%	±1%	±1%	±1%
Total weight		16T	23T	28T	37T	36T	46T	52T	70T
