product Description
JS1000 is twin shaft horizontal forced type mixer. It can mix dry hard concrete, plastic concrete, flowing concrete, light weight aggregate concrete and various mortar.
JS1000 concrete mixer has dual superiorities of working solely or forming simple concrete mixing plant with PLD1600 batcher. It has JS1000A and JS1000B two models. JS1000A can be used alone or as main mixing part of HZS50 plant . While JS1000B used as main mixing part of HZS60 plant.
JS1000 concrete mixer is widely applied in all kinds of large, middle, and prefabricated concrete plants, highways, bridge project, water conservancy, wharfs, etc.
Parameter
| Model | JS1000 | |
| Discharge capacity(L) | 1000 | |
| Charge capacity(L) | 1600 | |
| Theory productivity(m³/h) | ≤60/50 | |
| Max. aggregate diameter(mm) | ≤60/80 | |
| Working cycle time(s) | 60/72 | |
| Total weight(kg) | 5500 | |
| Outline dimension(mm) | Transporting | 3800×2200×2800 |
| Operating | 10460×3400×9050 | |
| Agitating vane | Rotational speed (r/min) | 29.6 |
| Count | 2×8 | |
| Agitator motor | Model | Y180M–4 |
| Power(KW) | 2×18.5 | |
| Hoist motor | Model | YEZ160L–4 |
| Power(KW) | 15 | |
| Pump motor | Model | 80JDB–45 |
| Power(KW) | 3 | |
Features
01.
High mixing evenness, short mixing time, long life span for wearing parts.
02.
High Wear-Resistant Chromium-Manganese Alloys Liners and Blades.
03.
The shaft end sealing system is by multi-sealing structure effectively prevents leakage and guarantees the continuous long running of whole mixing system.
04.
Automatically lubrication system ensures good lubrication effect and reduces maintenance cost.
05.
Double Full copper Motors and Speed Reducers, Stable and Long Life.
06.
Discharge height 3.8m-4.2m optional.
