product Description
JS2000 Concrete mixer is a powerful and high capacity concrete mixer with productivity of 2000L Per batch, tailored for large scale construction projects and commercial operations, it provide exceptional mixing performance with its double shaft mechnism. The JS2000 is perfect for high-demand environments where efficiency and quality are paramount,making it a top choice for bussinesses looking to scale up their concrete production.
JS2000 concrete mixer is a twin shaft horizontal forced type mixer. can be used separately or work together with a concrete batching machine for HZS120 concrete batching plant. It can mix dry hard concrete, plastic concrete, flowing concrete, light weight aggregate concrete and various mortar, it is a high-efficiency machine with wide application.
Parameter
| Model | JS2000 | |
| Discharge capacity(L) | 2000 | |
| Charge capacity(L) | 3200 | |
| Theory productivity(m³/h) | ≤120 | |
| Max. aggregate diameter(mm) | ≤80/100 | |
| Working cycle time(s) | 60 | |
| Total weight(kg) | 8800 | |
| Outline dimension(mm) | Transporting | 3500×2400×2152 |
| Operating | ||
| Agitating vane | Rotational speed (r/min) | 24.5 |
| Count | 2×8 | |
| Agitator motor | Model | Y250M–6 |
| Power(KW) | 2×37 | |
| Hoist motor | Model | |
| Power(KW) | ||
| Pump motor | Model | |
| Power(KW) | ||
Features
High Efficiency
The number of mixer blades is one time more than common double horizontal shaft mixer: for common concrete production, it just takes 20 seconds mixing time and gets the homogeneous end products, and its actual efficiency is over 20% more than common mixer; for high performance concrete, it just takes 35 methods and the actual efficiency is over 50% more than common mixer.
Low Energy Consumption
It uses the structure design of large space and low volume utilization rate, so the spacious space can make the mixing process much easier; the blades can continuously push the material to form a high-speed circulation with a small impact load and low energy consumption; after the rigorous comparison test, it can save over 15% energy consumption than the traditional mixer host.
High Durability
The blades are made of high anti-abrasion alloy cast iron, combined with the perfect mixing device to improve the material flow, which reduce the friction between the aggregates and blades, and its service life reaches up to more than 60,000 cans.
Long Service Life
The discharging door is at the JS2000 concrete mixer adopts imported advanced components and the diameter of its mixing tank is half smaller than the vertical mixer with the same capacity. The rotation speed of it is half slower than the vertical mixer, so the abrasion degree of its blades and liner plats is smaller and its service life is longer.
