product Description
We own a professional R & D, design, production, installation team, and provide users with one-stop service, including the process design,automatic control,transportation,installation, commissioning and personnel training.
We can provide various capacity of bolted cement silos from 50t to 1000t, welcome customization.
Parameter
| Type | Volume | Total Weight | Tank diameter | Tank height | Total height | Matched host | Matched screw conveyor |
| SNC 50 | 50T | 4.2T | 3m | 5.4m | 12m | JS500 | LSY185-6 |
| SNC 100 | 100T | 5T | 3m | 12.4m | 18m | JS1000 | LSY200–9 |
| SNC 150 | 150T | 5.5T | 3.2m | 16.5m | 18.6m | JS1500 | LSY250–9 |
| SNC 200 | 200T | 10.2T | 4.5m | 13.6m | 18.6m | JS2000 | LSY300–9 |
| SNC 300 | 300T | 11.8T | 5.5m | 15.6m | 18.6m | JS3000 | LSY300–9 |
| SNC 500 | 500T | 28T | 6m | 15.6m | 18.6m | ||
| SNC 625 | 625T | 29.5T | 6.5m | 16.6m | 18.6m |
Features
01.
Modular vertical structure saves the construction area.
02.
Customized sizing and layout to specific requirements
03.
High storage capacity
04.
Waterproof, moistureproof, prevent the loss of cement, and reduce urban air pollution
05.
Long service life
