product Description
With a production capacity of 750L per batch,JS750 concrete mixer strikes a balance between effiency and size,catering to both small businesses and more demanding household applications. It robust double shaft mixing system and consistent mixing, enhancing the quality of your concrete. the JS750 delivers reliable performance and versatility for various construction needs.
JS750 concrete mixer could work independently or in HZS35 concrete batching plant with PLD1200 batcher, is widely used in engineering construction such as roads, bridges, dams, and ports.
Parameter
| Model | JS750 | |
| Discharge capacity(L) | 750 | |
| Charge capacity(L) | 1200 | |
| Theory productivity(m³/h) | ≤35 | |
| Max. aggregate diameter(mm) | ≤40/60 | |
| Working cycle time(s) | 72 | |
| Total weight(kg) | 5000 | |
| Outline dimension(mm) | Transporting | 3110×2620×2580 |
| Operating | 5025×3100×5680 | |
| Agitating vane | Rotational speed (r/min) | 26 |
| Count | 2×7 | |
| Agitator motor | Model | Y200L–4 |
| Power(KW) | 30 | |
| Hoist motor | Model | YEZ132M–4 |
| Power(KW) | 7.5 | |
| Pump motor | Model | BL18–16–1.1 |
| Power(KW) | 1.1 | |
Features
01.
Twin shaft concrete mixer produces high quality concrete at high speed with outstanding reliability.
02.
It combines an extra-rigid frame with work proven power train and innovative shaft seals that can last for the life of the mixer.
03.
The twin shaft mixer is ideal for large batches of wet precast, SCC and ready-mix concrete.
04.
Discharge system: Pneumatic & manual discharge mode, low noise.
05.
Liner and mixer blade adopts high rigidity wear resistant steel (long service life).
06.
The height of discharge: 3m-3.8m (optional)
